Frame: Q235 hot-dip galvanized steel pipe, not easy to rust, service life 15-20 years
Exterior cover: White - 850g double-sided coated PVC fabric, blackout, 100% waterproof, UV resistant, frame resistant, tear resistant, self-cleaning
Front: tempered glass wall and glass door with curtain
• Frame: Q235 hot galvanized steel pipe, baked paint
• Steel treatment: hot galvanized
• Roof cover: double-sided coated PVC fabric, 100% waterproof, UV resistant, flame retardant, self-cleaning
• Diameter: customized
• Color: white, transparent, etc.
• Accessories: glass door, curtain, decorative lining, insulation, ventilation window, etc.
• Installation: easy to assemble and dismantle, movable. No poles inside, 100% tent space can be utilized.
• Wind load: 100km/h
• Snow load: 75KG/square meter
Standard sizes: (diameter 4m to 50m)
| Size(m) | Top Hight(m) | Frame Pipe Diameter(mm) | Wind Load(KM/H) |
| 4*6 | 3.3 | 48*2 | 100 |
| 5*7 | 3.5 | 48*2 | 100 |
| 6*8 | 3.9 | 48*2 | 100 |
| 6*9 | 6.1 | 60*2 | 100 |
| 4*7 | 3.5 | 48*2 | 100 |
| 5*7 | 3.5 | 48*2 | 100 |
| 6*8 | 3.9 | 48*2 | 100 |
| 6*10 | 6.1 | 60*2 | 100 |
Single swing glass door
Door frames
Insulation
Electronic lock glass door
PU leather insulation
Partition
Automatic skylight curtain
Solar exhaust fan
Single rail curtain
Double rail curtain
Quiet exhaust fan
Toilet
All-in-one bathroom
Bathroom cabinet
Indoor floor
External dimensions: length 11600mm, width 3300mm, height 3200mm Area: 38.8㎡
Accessories: sauna stones, wooden bucket, wooden spoon, humidifier, clock face, explosion-proof light, ceiling tiles, stones, backrest, stove, wooden box packaging
Creating a valley-like outdoor experience
